Types of window alarm sensors
Nearly 56% of burglaries involve forcible entry. Window sensors add another layer of security to combat home burglaries and other crimes.
While these add-ons increase the cost of home security systems, dedicated window sensors address the vulnerabilities and limitations of relying on cameras alone.
| Sensor Type | Detects | Best for | Pros | Cons |
|---|---|---|---|---|
| Contact sensors | Window movement | Windows not easily monitored by motion-activated cameras | Wireless easy-install versions available | Poor installation can lead to false alarms |
| Glass break sensors | Sound or vibration | Fixed windows | Works for windows that do not open | Prone to false alarms from loud music and barking dogs |
| Motion sensors | Movement using technology such as passive infrared (PIR) | Simple, low-cost systems | Many DIY options are available | Most PIR is vulnerable to blockage by window glass |
Contact sensors: Best for detecting open windows
Sometimes called open sensors, window contact sensors are small devices that alert you when windows are opened.
Contact sensors have two parts: the sensor itself — a reed switch — and the magnetic component. One part gets placed on the window frame and one on the window. When the window opens, the magnetic connection breaks, which triggers an alarm.
Contact sensors are the most common window-specific device used in home security systems and are generally very easy to install.
However, sensor misalignment leads to false alarms. DIY wireless systems often rely on batteries, which must be replaced. Wired sensors require installation by a qualified professional.
Glass break sensors: Best for fixed windows
Glass break sensors are a second line of defense, not a replacement for contact sensors, cameras or motion alert devices.
Sometimes, breaking a window is faster than other methods of entry for criminals. Glass break sensors are designed to detect this type of intrusion and are particularly helpful for protecting larger windows that do not open, such as picture windows.
Glass break sensors come in several varieties. Some are mounted directly on the window glass and get activated by vibration (shock). Others, mounted on ceilings or walls above windows, listen for specific audio frequencies or sudden, sharp bursts of sound.
A potential drawback to this type of window alarm sensor is that loud music, barking dogs and sonic booms may trigger false alarms.
Motion sensors: Best for broader area coverage
The most common home security device is a motion-activated camera. While contact alarm sensors specifically focus on windows, motion sensors often cover a wider area.
Most home security motion sensors use passive infrared technology, which detects changes in infrared radiation (heat) to sense motion. However, higher-end systems sometimes use other motion-detection technologies such as ultrasonic sensors (which emit high-frequency sound waves) and microwave sensors (which use microwave pulses to detect movement).
Home motion detectors that are designed to protect windows suffer from several limitations. Glare and backlighting are major challenges, so these factors should be addressed when determining the placement of security cameras. Additionally, movement from pets, foliage or balloons can cause false alarms with motion sensors.
» EXPLORE: The best home security systems
Window contact sensors explained
Contact sensors rely on magnetic fields and motion to trigger alerts. Precise installation is critical, so most people find professionally installed contact sensors more reliable.
How magnetic contact sensors work
Contact sensors use a two-part magnetic system with a reed sensor and a magnet. The sensor mounts on the window frame, while the magnet attaches to the window. Opening the window disrupts the magnetic field and triggers an alarm.
Surface mount vs. recessed contacts
Most window contacts use either surface or recessed mounting. Surface-mounted contacts are visible and installed on top of windows, while recessed contacts are hidden within the framing for a flush appearance — and, oftentimes, improved accuracy.
Surface-mounted window contact sensors are most common for DIY home security installations, while recessed contacts are more commonly installed professionally.
Wireless vs. wired contact sensors
Choosing between wireless and wired contact sensors involves different considerations.
Wireless sensors are easier to install because they communicate with the security system by radio signal. They’re also portable, so you can take them with you when you move. However, they need batteries and are visible.
Wired sensors connect to the system using physical wires and do not need batteries. They also come in recessed versions. Of course, wired sensors require installation by a professional.
Common placement and alignment mistakes
If you rent, use a wireless security system to avoid drilling and making permanent modifications to the property.
The most common installation mistakes for contact window sensors are uneven alignment and incorrect placement on windows. These errors lead to a lack of legitimate alarms or an increase in false alarms.
Uneven alignment can place sensors too far apart, weakening the magnetic field. Sensors may be offset so the window always appears open. Some users install pairs on parts of the window that don’t open, so contact is never broken — even when the window opens.
Glass break sensors and vibration sensors
If your windows don’t open or you want extra protection, glass break sensors might help. These sensors use vibrations and sound. They are less invasive than in-home video cameras.
Acoustic vs. shock vs. dual tech
Glass break sensors in home security generally rely on listening for sound, feeling vibration or both.
| Glass break sensor | Primary operation | Key disadvantages |
|---|---|---|
| Acoustic glass break sensors | Uses microphones to monitor for specific frequencies, volume and sudden sounds | Vulnerable to glass being cut; some specialty glass types (e.g., tempered, laminated, or reinforced security glass) may not trigger alarms when breaking; false alarms from sharp, sudden noises (e.g., dog barks) are common |
| Shock glass break sensors | Sensors on the glass monitor strong vibrations indicative of breaking | Vulnerable to glass being cut and may give false alarms for loud music |
| Dual-tech glass break sensors | Uses sensors of both types together; both indicators must trigger for an alarm to activate | Reduces false alarms but may not always trigger when needed |
Coverage range and sensor placement
Most window sensors are designed for one window. For example, contact sensors and shock glass break sensors are window-specific. However, motion and acoustic sensors may cover several windows.
The exact range varies by method, sensor type and obstructions. Some acoustic sensors cover about 25 feet. Motion detection cameras vary. Pro outdoor models may reach 100 feet, while even the best DIY home security cameras may only reach 25 to 40 feet.
Smart doorbells or add-on motion detection for windows may cover only 15 feet. Check with each company for detailed information before installation.
» MORE: Best self-monitored home security systems
Reducing false alarms from loud noise
False alarms usually come from poor installation or incorrect settings. Most alarm systems let you adjust sensitivity. For example, if you have a dog at home that likes to bark, you can set your system to be less sensitive to sound and vibration.
Loose windows that rattle can also cause false alarms. Though adjusting the sensitivity settings may help, repairing these windows is best.
Choosing window alarm sensors for your home
Picking the right home window alarm system depends on a variety of factors. Consider your budget, types of windows, risk, existing security and installation. Keep a checklist to help you narrow the types of window alarm sensors you should choose from.
Key factors to consider when choosing window sensors
Every home is different, but all share common key elements worth considering when shopping for types of window alarm sensors.
- Window type: Window sensor needs vary depending on whether or not a window opens.
- Entry risk: Larger windows on the ground floor pose the most entry risk.
- Floor level: Ground-floor windows are most often targeted. Upper floors near trees or trellises may also be at risk, but these areas may need fewer sensors than lower windows.
- Pets: Barking dogs sometimes set off glass break alarms, and pet motion frequently triggers motion alarms.
- Smart home compatibility: Not all smart home systems work with all window sensors. Choose a complete package for best results.
- Monitoring: Professionally monitored systems often offer more choices of sensor types than DIY self-monitored home alarm systems.
- Budget: If your home has a lot of windows or you prefer recessed, hard-wired sensors, add sensors over time to stay within budget.
- Installation preference: Renters may find that landlords prefer contact-adhesive window sensors, as they don’t require drilling or cutting into the home. Others may prefer professional installation for more advanced sensors.
How window type affects sensor choice (sliding, casement, fixed, basement)
Not all sensors fit every window. Contact sensors don’t work for fixed windows. Motion detectors may face problems with blocked basement windows. Location often determines which sensor is best when there are options.
| Window style | Description | Best window alarm sensor type |
|---|---|---|
| Fixed window | A window that doesn't open, such as a picture or bay window | Glass break (vibration, sound or dual-tech), motion detection |
| Single or double-hung window | A “standard” window that slides upward or downward to open | Glass break (vibration, sound or dual-tech), motion detection, contact sensors |
| Sliding window | Window that slides to one side on a top and bottom track, much like a sliding glass door | Glass break (vibration, sound or dual-tech), motion detection, contact sensors |
| Casement window | Hinged to swing out (or in), similar to a door | Glass break (vibration, sound or dual-tech), contact sensors |
| Awning window | Similar to a casement window, but it swings outward to open | Glass break (vibration, sound or dual-tech), motion detection, contact sensors |
| Basement window | Commonly fixed or awning style, but leads to a basement; frequently located slightly below ground level and protected by a retaining wall | Glass break (vibration, sound or dual-tech), contact sensors |
Budget considerations: Finding cost-effective window sensor options
Adhesive-based installation contact sensors are the most economical, but aren’t the best option for everyone. Plus, if you have many windows, you may find yourself needing to rely on motion-sensor cameras without an added sensor per window. Likewise, while recessed installation is the least intrusive visually, it is the most expensive.
When shopping for security, compare multiple provider offerings to find the best window sensors for home security. For example, turnkey solutions such as ADT vs. Guardian Protection or turnkey vs. DIY options such as Guardian Protection vs. Simplisafe.
Draw up a list of questions to ask, and plan ahead for items such as how many security cameras you need, so you are prepared to get the best deal.
» RELATED: Questions to ask a home security company
FAQ
How do magnetic window sensors work?
Magnetic window sensors have two parts: a sensor and a magnet. When the window opens, the pieces move apart and trigger the alarm.
Do window sensors work on all window types?
Not all window alarms work with all windows. Window sensors and window types need to be matched for best results.
What is the difference between wired and wireless window sensors?
Wired window sensors are connected to the security system hub by physical wires and wired into the home’s electrical system.
Can window sensors cause false alarms?
Window sensors can cause false alarms from sudden sounds, excessive vibration and improper installation.
How much do window alarm sensors cost?
Window alarm sensor costs vary widely, with DIY sensors starting below $15 each and ranging to well over $85 each.
